Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature compensated charging. Automatic self tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy to connect, hot-swappable battery modules provide battery replacement without powering down.
| Country of Origin | USA |
| Topology | Double Conversion On-Line |
| Capacity | 10.0 KWatts / 10.0 kVA |
| Input Voltage | 230V, 400V 3PH (Nominal) |
| Output Voltage | Nominal: 230V |
| Frequency | Input: 40 – 70 Hz (auto sensing); Output: 50/60 Hz +/- 3 Hz |
| Input Connection | Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G) |
| Output Connection | (6) IEC 320 C13 (Battery Backup), (4) IEC 320 C19 (Battery Backup), (1) Hard Wire 3-wire (H N + G) (Battery Backup), (3) IEC Jumpers (Battery Backup) |
| Efficiency | at Full Load: 94 . 6 % |
| Recharge Time | Typical 1.5 hour(s) |
| Interface | RJ-45 10/100 Base-T , RJ-45 Serial , Smart-Slot , USB |
| Protection | Class: IP 20 |
| Control Panel | Multi-function LCD status and control console |
| Waveform Type | Sine wave |
| Surge Energy Rating | 480 Joules |
| Crest Factor | 3 : 1 |
| Bypass | Built-in Bypass (Automatic and Manual) |
| Environment | Operating; 0-40 °C; Storage:-15-45 °C |
| Relative Humidity | 0 – 95 % |
| Noise Level | 55.0 dBA; Audible and visible alarms prioritized by severity |
| Approvals | CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, VDE |
| Dimension | HxWxD: 432mm, 43.2CM; 263mm, 26.3CM; 715mm, 71.5CM |
| Weight | 111.82 KG |
| Warranty | 1 Year |
